Item specifics
  • Item Type: LED Bulbs
  • Certification: UL,CE,FCC,RoHS,CCC
  • Shape: Globe
  • Led Bulb Type: Bubble Ball Bulb
  • Brand Name: sumbulbs
  • Luminous Flux: 2000 Lumens & Above
  • Number of LED Chip: other
  • Power Tolerance: 1%
  • Voltage: 3-3.5V/W
  • LED Chip Brand: Epistar
  • Occasion: living room
  • LED Chip Model: 2W High Power
  • Beam Angle(°): 120°
  • Average Life (hrs): 50,000
  • Color Temperature: Nature White(3500-5500K)
  • Length: 28mm
  • Base Type: COB
  • Product name: 2820 COB LED chip
  • Diameter/ Size: 28mm
  • Lighting diameter: 20mm
  • Light color: Cool white/ Natural white/ warm white
  • Light temperature: 2700K - 6500K
  • Material: Aluminum-alloy & Silicone rubber
  • Weight: 0.025kg
  • Luminous efficacy: >100LM/W
  • Power: 3/ 5/ 7/ 10/ 12W
Product Description

Sumbulbs LED integrated chip COB light source for LED lamps bulbs 20mm lighting diameter warm/ nature/ cool white 20PCS



Please note that the unite price is for 20 pieces COB together!



product description LED bulb cob lamp led lighting

1. COB for LED bulbs (SBS-2820)

2. Diameter: 28mm

3. Lingting diameter: 20mm

4. Power: 3W/ 5W/ 7W/ 10W/ 12W

5. Rated current: 300mA   ,Foword Voltage :9-11V(3W)  ; 15-17V(5W)  ; 21-24V(7W)  ; 30-33V(10W) ; 36-40V(12W)

6. Lignt temperature: 2700K-6500K

7. Lingt color: Warm white/ Nature white/ Cool white

8. RA: 70% - 90%

9. Luminous efficacy: more than 100LM/W

10. Usage:

- Low power consumption, save whole lot of energy

- Ideal for DIY use

- Great for making light sources for video camera, fish tank, decoration light

- Among different LED components such as high power LED, SMD, dip etc, COB LED is best in thermal resistance and cooling.

Sumbulbs 1W-100W COB LED Strip Light Lamp Red Blue Warm Natural Cold White Rectangle LED Matrix Chip on Board Bulb for DIY (1)



PICTURE LED bulb cob lamp led lighting

/common/upload/147/118/071/549/1471180715495_fileserver011230150065_407714.jpg

/common/upload/147/118/083/873/1471180838739_fileserver011230150069_407926.jpg

/common/upload/147/118/072/778/1471180727780_fileserver011230151172_407448.jpg

/common/upload/147/118/075/386/1471180753867_fileserver011230150068_407578.jpg

Color Testing  LED bulb cob lamp led lighting



For more LED COB light, please click here:

5W 10W 20W 30W 50W 200W Rounded COB LED Light Source Warm Natural Cold White Integrated Circular LED Chip On Board Bulb Lamp (2)



1W 100W COB LED Strip Light Lamp Red Blue Warm Natural Cold White Rectangle LED Matrix Chip on Board Bulb for DIY





knowledge LED bulb cob lamp led lighting

What is COB?

COB (Chips on Board) is a new technology of LED packaging of LED light engine. Multi LED chips are packaged together as one light module. When it lights up, it looks like a lighting panel.



How COB LED light source works?

In COB lighting, single LED chips are placed directly on a circuit board (or substrate) which has thermal properties to disperse heat. Heat dissipation is a very important aspect of LED lighting since it can have a major impact on the life expectancy of the luminary. Therefore, COB lighting can have a higher LED chip density and achieve higher light level while maintaining or improving life expectancy.



Advantage of COB:

COB lights are a more efficient form of LED lighting for general or automotive lighting applications because:

- light has a more uniform appearance

- better life expectancy

- achieve higher light level over a large area

- COB is more stable and reliable than standard LED package



Applications:
